De-scaling and de-sliming

De-slimer 701 & 1101

The De-slimers 701 and 1101 for whole de-headed salmon is for the optimal removal of slime and blood before and after gutting and before filleting.

Download brochure

With special high pressure flat beam nozzles mounted on stainless high pressure nozzle pipes, it is possible to individually adjust each nozzle pipe and hereby obtain the optimum spraying pattern. The nozzles can easily be dismantled for service and cleaning.

The infeed conveyor of the machine is fitted with 1 set of photocells. The washing section automatically starts when the fish comes through, and it stops when there are no more fish to minimize the water consumption.

	701	1101
Capacity	Max. 50 fish/min	Max. 90 fish/min
Water consumption	30 L/min	42 L/min
Dimensions	3550 x 950 mm	3550 x 950 mm
Belt width	700 mm	1100 mm
Motor	Variable speed 6 – 20 m/min	Variable speed 6 – 20 m/min
Electrical supply	12 kW, 3 x 400 V, 50 Hz*	15.5 kW, 3 x 400 V, 50 Hz*

* Please contact our sales team for other power connection possibilities

Chemical dosing unit for final disinfection

Two pipes for inside washing of the fish

Photo cell control for automatic start/stop function

Head cutting section for two or four operators

Hygienic fish processing with efficient de-sliming

The deslimer ensures that the fish are clean before processing.

The desliming process is divided into two sections: the main wash and the final wash. Each wash is performed with high pressure water. The main wash removes slime and bacteria on both sides of the fish. The final wash rinses the fish inside and outside with clean water. This ensures hygienic fish processing.
